CB-63CX Moulded Case Circuit Breaker Datasheet & Manual

CB-63CX Moulded Case Circuit Breaker

The CHINT CB-63CX Moulded Case Circuit Breaker (MCCB) is designed to deliver reliable overload and short-circuit protection for AC circuits up to 415 V and 63 A. With thermomagnetic trip technology, a compact plug-in structure, and 6 kA breaking capacity, it ensures high safety and performance for power distribution systems. Built to IEC 60947-2 standards and certified by CE and TÜV, the CB-63CX MCCB provides durable and efficient circuit protection in commercial, industrial, and infrastructure applications.

Need Support From Us?

Blog

Find expert perspectives on the trends and technologies driving your business.

View Now

Download Center

Download new and previously released documents including product document, solutions, cases, coporate report.

View Now

Reach out to us to receive more information, technical support, assistance with complaints and more.

Collapsed

Expand

FAQs

What is the purpose of the CB-63CX MCCB?
The CB-63CX protects electrical circuits from overload and short-circuit faults in AC networks up to 415 V and 63 A, ensuring system safety and reliability.

What tripping mechanism does it use?
It features a thermomagnetic trip unit with an instantaneous trip setting of 8 × In ± 20 %, providing precise protection under different fault conditions.

What are the available pole configurations?
The CB-63CX is available in 2P, 3P, and 4P versions, supporting AC 230/240 V and 400/415 V systems.

Can it be installed in any position or configuration?
Yes. Both top and bottom feed lines are acceptable, and it mounts easily using a plug-in installation system compatible with standard distribution panels.

What environmental conditions can it withstand?
It operates reliably from −40 °C to +70 °C, up to 2000 m altitude, and offers IP20/IP40 protection, making it suitable for industrial and commercial environments.
