Introduction
Electric faults happen where they cannot be seen, so these are very risky in multi-story house buildings, where basically one problem can influence several flats. Given that shared infrastructure is subjected to heavy and random loads, the efficiency of the safety measures relies on the presence of different types of layered electrical safety devices, such as the molded case circuit breaker that can sense and, thus, interrupt short circuits at the earliest stages.
What Are the Causes of Electrical Fires in Multi-Unit Buildings?
Generally, an electrical fire does not result from a failure of the single component. Such fires develop as a consequence of events that either worsen gradually over time or occur suddenly during periods when the load is high. Among the most frequent causes of such fires are:
- Overloaded circuits operating beyond their intended capacity.
- Insulation that has deteriorated due to age, heat, or moisture.
- Loose terminations in panels or junction boxes that create localized hotspots
- Aging or unprotected wiring installed long before today’s safety standards.
These issues get magnified in multi-unit buildings for the following reasons:
- Higher appliance density: The air-conditioning, water-heating, cooking, and device-charging appliances of several units can push circuits to their maximum capacity.
- Diverse tenant usage: While some residents may run high-load appliances for the whole time, others may not use them at all. This uneven usage of risers and panel boards leads to their overloading.
- Shared infrastructure: Distribution boards, risers, and meter rooms are common to multiple units, so a fault in one section can lead to a failure in other parts of the building.
Because these risks accumulate in complex ways, preventing electrical fires requires a proactive protection strategy instead of reactive troubleshooting. Once a fault reaches the point of visible symptoms (burning smell, heat, or flickering), it has already progressed too far.
Electrical Safety Devices as the Foundation of Prevention
Automated detection is at the base of modern electrical fire safety. Protective devices keep an eye on electrical behavior all the time, and they intervene even before the conductors reach a dangerous temperature. Such devices operate at a speed a human cannot match, and they are able to detect those faults that are invisible even to the most thorough manual inspections.
Layer 1: Overcurrent and Short-Circuit Protection
The second layer of defense is made up of overcurrent protection devices such as miniature circuit breakers (MCBs) and molded case circuit breakers (MCCB). Generally, their main function is to stop the flow of an excessive current that can cause the overheating of the conductors or damage to the equipment.
These devices use both thermal and magnetic mechanisms for detecting abnormal load conditions. In case of an overload or a short circuit, the breaker disconnects the power supply to the affected circuit by turning off the electricity. Consequently, this avoids the wiring from being overheated, the distribution boards from getting hotspots, and the fault spreading to the other parts of the installation.
Such protection is indispensable in buildings with several units. Without proper settings, overloaded circuits may not trip at once, and old wiring may not be able to withstand the heat for a long time. Breakers that have stable and predictable performance help in the prevention of panel damage, equipment burnout, and cascading failures.
Layer 2: Leakage Protection
Leakage protection is essentially fault protection for situations where the current escapes its intended path—most of the time this is because the insulation has failed, or the device has gotten wet, or there is an accidental contact with the device. Residual current circuit breakers (RCCBs) and residual current circuit breakers with overload protection (RCBOs) are the devices that sense the minute leakage currents that even standard breakers are unable to detect.
Where the breakdown of the insulation in the wall is causing the leakage current, the heat can be produced in some parts of the house where people do not expect it. RCCBs and RCBOs do this by isolating the circuit whenever leakage is higher than allowed limits, thus they bring the risk of loss of fire to almost zero.
Layer 3: Arc Fault Protection
Arcing takes place when a short or damaged section of a wire causes the current to jump over a gap. Because of this, the arcs create very high temperatures in a very small area and for this reason, they can often set the materials that surround them on fire.
Most arc faults are not detected by traditional breakers because the current may not be high enough to cause the device to trip. This is the reason why there are arc fault detection devices (AFDDs). They keep track of the electrical waveforms and recognize the patterns that are typical for the arcing that is most likely to be dangerous.
Arc faults are among the most common causes of the hidden fires that often accompany the old installations of the wiring that has aged and the loose terminations. Getting them first, therefore, is a very important additional layer of the overall protection that is present.
How Molded Case Circuit Breakers Improve Fire Prevention
The molded case circuit breaker (MCCB) is a heavy-duty protective device that is intended for situations where the current rating and the fault-handling capacity are beyond what a miniature breaker can offer. The MCCB, which is in a molded insulating case, merges the mechanical operation with thermal-magnetic or electronic trip units.
The design of the MCCB makes it possible for it to have:
- The adjustment of the trip points to match the load characteristics.
- High breaking capacity to be used for main distribution panels.
- The ability to perform consistently even when the surrounding temperature is high.
MCCBs are the ones that especially come in handy in multi-unit buildings. The shared risers, main panels, and meter centers not only carry higher fault currents but also serve multiple units. So, if the circuit of one tenant has a fault, the shared components will bear the brunt of the hard work. MCCBs act as the safeguard that is dependable all over these systems, thus lessening the chances of overheating and improving the resilience of the building as a whole.
CHINT’s MCCB range comprises NXM, NXB-125, and NM8N to fulfill these demands.
- NXM MCCB: Covers frame sizes from 63A to 1600A with breaking capacities up to 70kA. Suitable for commercial and industrial applications requiring stable interruption of high fault currents.
- NXB-125 MCCB: Rated for 63A to 125A, with breaking capacities up to 20kA. Designed for both AC and DC circuits and suitable for final distribution boards.
- NM8N MCCB: Offers overload, short-circuit, and undervoltage protection, and supports motor and residual current protection. Flexible installation options make it effective across diverse building layouts.
Within a layered protection strategy, CHINT’s molded case circuit breaker solutions contribute high mechanical endurance, operating stability in temperatures down to –35°C, and strong breaking capacities, supporting dependable protection in demanding multi-unit building environments.
Detecting the Undetectable with Arc Fault Breakers
Arc faults develop when wiring becomes pinched, cracked, or loosened over time. In older apartment complexes, connections may have undergone decades of thermal cycling—expanding when loads are high and contracting as temperatures drop. This repeated stress can loosen terminations, creating gaps where arcs can form.
Arcing conditions generally fall into two categories:
- Series arcing: Occurs when a conductor breaks or a connection weakens.
- Parallel arcing: Happens when two conductors with different potentials come close enough for current to jump.
Both types can generate temperatures capable of igniting surrounding insulation or combustible materials.
An arc fault breaker (AFDD) monitors the electrical waveform in real time. Instead of looking solely at current magnitude, the device analyzes the unique patterns produced by arcing. When abnormal sparking is detected, it interrupts the circuit before the arc reaches ignition temperatures.
Pairing AFDDs with MCCBs, MCBs, and RCCBs forms a multi-layered strategy consistent with global best practices in electrical fire safety.
Preventing Electrical Fires Through Building-Wide Strategy
Property managers and electrical engineers can reduce risk across the building by focusing on several practical measures.
- Periodic thermal imaging: Identifying hotspots in panels or risers helps detect loose connections before they deteriorate further.
- Upgrading outdated breakers: Replacing older devices with modern units that offer higher sensitivity and stable performance ensures better protection.
- Standardizing equipment: Using compliant devices throughout meter rooms, risers, and distribution boards reduces inconsistencies in protection.
- Load balancing: Distributing loads evenly prevents certain circuits from being overworked, reducing thermal stress on wiring.
- Panel cleanliness and maintenance: Dust, debris, and corrosion can impair heat dissipation or cause tracking issues.
Conclusion
Preventing electrical fires in multi-unit buildings requires a forward-looking approach built on layered protection and consistent maintenance. MCCBs, leakage protectors, and AFDDs work together to identify and isolate faults before they escalate. CHINT supports these strategies with durable, compliant components that enhance system coordination and reduce building-wide risk through reliable electrical safety devices and thoughtful system design.
